Şeffaf D Tipi Mandallar Texas Instrument Entegre Devreler IC SN74LVCH16373ADGGR
SN74LVCH16373ADGGR Entegre Devreler IC
,SN74LVCH16373ADGGR TI Ics
SN74LVCH16373ADGGR Şeffaf D Tipi Mandallar Texas Instrument Entegre Devreler IC
Texas Instruments(Elektronik parçalar )
SN74ABT162841DGGR SN74ABT16841 SN74ABT16843 Şeffaf D-tipi Mandallar Texas enstrüman Entegre Devreler IC
Özellikler:
'ABT16373A, yüksek kapasitif veya nispeten düşük empedanslı yükleri sürmek için özel olarak tasarlanmış 3 durumlu çıkışlara sahip 16 bit şeffaf D tipi mandallardır.Arabellek kayıtları, G/Ç bağlantı noktaları, çift yönlü veri yolu sürücüleri ve çalışma kayıtları uygulamak için özellikle uygundurlar.
Bu cihazlar iki adet 8 bitlik mandal veya bir adet 16 bitlik mandal olarak kullanılabilir.Mandal etkinleştirme (LE) girişi yüksek olduğunda, Q çıkışları veri (D) girişlerini takip eder.LE düşük alındığında, Q çıkışları D girişlerinde ayarlanan seviyelerde kilitlenir.
Sekiz çıkışı normal mantık durumuna (yüksek veya düşük mantık seviyeleri) veya yüksek empedans durumuna yerleştirmek için arabelleğe alınmış bir çıkış etkinleştirme (OE) girişi kullanılabilir.Yüksek empedans durumunda, çıkışlar bus hatlarını önemli ölçüde yüklemez veya sürmez.Yüksek empedans durumu ve artırılmış sürücü, arabirim veya çekme bileşenlerine ihtiyaç duymadan veri yolu hatlarını çalıştırma yeteneği sağlar.
OE, mandalın dahili işlemlerini etkilemez.Çıkışlar yüksek empedans durumundayken eski veriler tutulabilir veya yeni veriler girilebilir.
- Özellikler:
Kategori | Entegre Devreler (IC'ler) |
Mantık ve voltaj çevirisi | |
Mfr | Texas Instruments |
Diziler | Şeffaf D-tipi Mandallar IC'ler |
paket | Tepsi ve Makara (TR) |
Parça Durumu | Aktif |
PLL | Evet |
Ana amaç | Genel amaç |
Çalışma sıcaklığı | -40°C ~ 85°C |
Montaj tipi | Yüzey Montajı |
Paket / Kasa | SOIC |
Ürün numarası | SN54ABT16373A SN54ACT373 SN54ACT573 |
Kanal Sayısı (#) | 16 |
Teknoloji Ailesi | ABT |
Besleme gerilimi (Min) (V) | 4.5 |
Besleme gerilimi (Maks) (V) | 5.5 |
Giriş tipi | TTL-Uyumlu CMOS |
Çıkış tipi | 3-Devlet |
Saat Frekansı (Maks) (MHz) | 150 |
GİL (Maks) (mA) | 64 |
IOH (Maks) (mA) | -32 |
ICC (Maks) (uA) | 89000 |
Özellikler | Çok yüksek hız (tpd 5-10ns), Kısmi güç kapatma (Ioff), Güç açma 3 durumlu, Akışlı pin çıkışı |
VCC 0 ile 2,1 V arasında olduğunda, güç açma veya kapatma sırasında cihaz yüksek empedans durumundadır.Ancak, 2,1 V'un üzerinde yüksek empedans durumunu sağlamak için, OE, bir çekme direnci aracılığıyla VCC'ye bağlanmalıdır;direncin minimum değeri, sürücünün akım kesme kapasitesi ile belirlenir.
SN54ABT16373A, -55 °C ila 125 °C arasındaki tüm askeri sıcaklık aralığında çalışmak üzere karakterize edilmiştir.SN74ABT16373A, -40°C ile 85°C arasında çalışacak şekilde karakterize edilmiştir.
